62¼" x 32⅛" ADA Linear Drain Roll In Shower, Left Seat

Out of Stock
(Shower stall only)

62¼" x 32⅛" ADA Linear Drain Roll In Shower, Left Seat

Out of Stock
Handed by Seat wall 1-Piece, New Construction (60"x 30"ID)
Model: APFXST6232LD1.125L
Made in America

US$3,794.00 Save 32% US$5,557.00

(Shower stall only)

Model: APFXST6232LD1.125L
Made in America

Out of Stock
Out of Stock

Freedom Linear Trench Drain ADA Showers have a 60” x 30” inside dimension to meet ADA requirements for roll in showers. For new construction projects install perfectly designed one-piece ADA roll in showers with zero entry.

The integrated linear drain keeps water from running onto the bathroom floor. The 1⅛" threshold is designed for flush zero barrier shower entrance design. To meet ADA code requirements the shower may need to be recessed or bathroom floor will need to be built up to meet the threshold.

Linear Drain Freedom Shower is Code Compliant

The pan of the ADA handicapped accessible shower is pre-leveled and sloped towards the drain. These ADA compliant roll in showers have a modern large subway tile pattern, with durable, easy-to-clean applied acrylic finish.

To support added grab bars and accessories the walls are reinforced to add structural reinforcement. Order with a factory installed folding shower seat and grab bars to meet ADAAG guidelines for an ADA compliant roll in shower. A great choice for large projects, senior living or assisted living facilities, Freedom Showers are easy to install, simplifying your construction project. For peace of mind, Freedom Showers come with a 30 year manufacturer's warranty.


ADA Linear Drain Roll In Shower:

  • Outside pocket dimensions: 62¼”w x 32⅛”d x 78¾”h
  • Inside dimension 60” x 30” x 76¾"
  • ADA compliant when properly installed
  • California Title 24 compliant
  • 1-piece for new construction
  • Integral front trench drain, with stainless grate
  • 1⅛" skirt  exterior threshold
  • Handed by the Left Seat side
  • Self-supporting, pre-leveled shower base
  • 12" x 24" subway tile pattern
  • Easy-to-clean applied acrylic finish
  • Textured slip-resistant floor
  • Full reinforced backing
  • Made in America
  • 30 Year Manufacturer’s Limited Warranty

Available Accessories:

  • L shaped padded Folding Shower Seat (factory installed)
  • Grab Bars (factory installed)
  • Shower Rod (ships loose)
  • Weighted Curtain
  • Pressure Balance Mixing Valve
  • Hand-held Shower and Slide Bar
  • Caulkless Drain
  • Large recessed soap dish (shipped loose)
  • Small recessed soap dish (shipped loose)


Click here for California Prop 65 Warning


Product Specification (PDF) 04/07/2018 167.45KB
Installation (PDF) 25/03/2019 2.18MB
Soap Niche Installation (PDF) 09/06/2021 1.1MB


Freedom Showers Linear Drain Informational Video

Freedom Showers Linear Drain Informational Video

The Freedom Linear Drain shower stall offers simple functional installation. Popular in hospital and Aging in Place settings, this durable shower will can meet commercial ADA code compliance. This shower stall is wheelchair accessible and can be fully equipped with accessories.

Linear Drain Shower Installation Video from Freedom Showers

Linear Drain Shower Installation Video from Freedom Showers

This video illustrates the installation process for a Freedom Trench Drain Shower.
